| MODEL | VDM-50 | ||
| Plant Capacity (TPH)* | 60-90 | ||
| Dimension of Thermo | – | ||
| Drum Unit (L×W×H) (m) | 11.80 × 2.70 × 2.80 | ||
| Burner Size (J/H) | 300-350 | ||
| Burner Type | HI-LO TYPE | ||
| Jet | PRESSURE JET | ||
| Fuel Type | HSD, LDO | ||
| Exhauster Unit (CFM) | 14500 | ||
| Dust Collector (m) | 0.15 | ||
| Feeder Capacity (kg) | 44000 | ||
| Bitumen Tank (L) | – | ||
| Filter Capacity (kg) | 1000 | ||
| Power Required Total (kW) | 94.38 | ||
| Total Area Required (m) | 38×38 | ||
| GEAR DETAIL | |||
| Auxiliary Conveyor | SMSR TYPE (C Type) | ||
| Gathering Conveyor | SMSR TYPE (E Type) | ||
| Slinger Conveyor | SMSR TYPE (D Type) | ||
| Loadout Conveyor | SMSR TYPE (F Type) | ||
| Drum Drive Unit | SNU WORM TYPE 8 | ||
| Bitumen Pump | GEAR TYPE 2”×2” | ||
| *3% Moisture Content in Cold Aggregates, 38°C Atmospheric Temperature, Aggregated Density of 1.6 Tons/m³, Mean Sea Level. | |||
